With increasing manufacturing and machine quality, the surface finish technical products' is becoming ever more important than ever. This makes it all the more crucial to offer metrological solutions with instrument designs that provide quick and simple yet standards-compliant measuring options. In some cases measurements are transferred from the inspection room to production to save time and money.
Components may be too large or heavy to be transported, leaving no alternative but to carry out measurements directly on the component or machine. The Pocket Surf PS1 lives up to its claim of 'Absolute mobility' in all manner of ways, providing: ● Battery powered freedom Over 500 measurements without having to recharge the instrument. ● An all-in-one solution that is no larger than a digital camera. Small and lightweight (400g / 0.88 lbs.). ● Instrument flexibility The standard range of functions is sufficient for this all-purpose smart little instrument to perform your measuring tasks.
● All the measuring positions you need Can be used horizontally, vertically, upside down or in any other position required by the component. ● 24 parameters Offer the same range of functions as a laboratory instrument. ● Error-free operation thanks to an integrated roughness standard.
The 6910205 Mahr Federal MarSurf M300/PS1 Explorer Software is on sale at Gaging.com! MarSurf Explorer software - (Must be V1.20-07 or later for use with M300) Graphical PC interface to simplify transferring, viewing and printing results and profiles from the PS1 on a desktop PC. For use with Windows 2000/XP.
● Automatic cutoff selection (Patented) so that even non-specialists are ensured correct measuring results. ● Simple operation The pocket surf shows how simple the PS1 is to use. You quickly get to grips with the essential features, enabling you to complete your measuring tasks with excellent results. 80 mm (3.15 in) pick-up extension for example, for measuring points located deep within cylinders. 6850540 PHT 3-350 pick-up for measuring in bores from dia.
3mm (0.12 in). 6111521 PHT 11-100 pick-up for measurements at recessed measuring points, e.g. In groves from 2.5mm (0.10 in) wide and up to 7.5mm (0.30 in deep.
6111524 PHTR 100 pick-up for measurements on concave and convex surfaces. 6111525 PHTF 0.5-100 pick-up for measurements on tooth flanks. 6111522 PT 150 pick-up Dual-skid pick-up for measurements on metal sheets and roller surfaces according to DIN EN 10049 (SEP). 6111523 Pick-up set (not illustrated) consisting of ● PHT 3-350 pick-up (6111521) ● PHT 11-100 pick-up (6111524) Order No. 6910213 Accessory set (not illustrated) consisting of ● Pick-up extension (6850540), length 80mm (3.15 in ● Adapter for transverse tracing (6850541) ● Measuring stand mount (6910201) Allows the Pocket Surf PS1 to be mounted on the Mahr ST-D / ST-F / ST-G family of measuring stands. ● End face vee-block (6910203) Suitable for measurements on flat faces of cylindrical and planar components Order No.
Unit of measurement Metric, inch Measuring principle Stylus method Pick-up Inductive skidded prick-up, 5µm (200µin) stylus tip, measuring force approx. 0.7 mN Parameters Ra, Rq, Rz equiv. To Ry (JIS), Rz (JIS), Rmax, Rp, Rp (ASME), Rpm (ASME), Rpk, Rk, Rvk, Mr1, Mr2, A1 (24, with tolerance limits) A2, Vo, Rt, R3z, RPc, Rmr equiv. To tp (JIS, ASME,), RSm, R, Ar, Rx Languages 14 including 3 Asian languages Measuring Range 350µm, 180µm, 90µm (changes automatically) Profile resolution 32nm, 16nm, 8nm (changes automatically) Filter Phase-correct profile filter (Gaussian filter) acc. To DIN EN ISO 11562, special filter acc.
To DIN EN ISO 13565-1, Is filter acc. To DIN EN ISO 3274 (can be disabled) Cutoff lc. 0.25mm, 0.8mm, 2.5mm; automatic (0.010in, 0.030in, 0.100in) Traversing length Lt. 1.75mm, 5.6mm, 17.5mm; automatic (0.069in, 0.22in, 0.69in) Traversing length (acc. To MOTIF) 1mm, 2mm, 4mm, 8mm, 12mm, 16mm, (0.040in, 0.080in, 0.160in, 0.320in, 0.480in, 0.640in) Short cutoff. Selectable Evaluation length In. 1.25mm, 4.0mm, 12.50mm (0.050in, 0.15in, 0.50in) Number n of sampling lengths.
Selectable: 1 to 5 Calibration function Dynamic Memory capacity Max. 15 profiles, max. 20,000 results. Pocket Surf PS1. The Set The Pocket Surf PS1 comes in a complete set. Thanks to the carrying case, you always have your surface roughness measuring instrument with you as you pass through the production floor. Quick and reliable on the spot measurements ensure your quality requirements are met during the production process or goods inspection.
The set contains ● Drive unit ● 1 standard pick-up 5µm (200µin) stylus ● battery ● Roughness standard integrated into unit ● Height adjustment accessory ● Pick-up protection ● Charger ● Operating instructions ● Carrying case with shoulder strap and belt loop ● USB cable ●Mahr Calibration Certificate ● Pocket Surf PS1 base Order No. 6910214 Pocket Surf PS1. Available Parameters Parameter Output Meaning Standards Ra RA Arithmetic means roughness Ra DIN EN ISO 4287: 1998; ISO 4287: 1997; JIS B 0601: 2001; ASME B46 Rq RQ Root mean square roughness Rq DIN EN ISO 4287: 1998; ISO 4287: 1997; JIS B 0601: 2001; ASME B46 Rz RY (JIS) equiv.
Marsurf Ps1 Explorer Software S Free
Mahr MarSurf M400 Bluetooth Surface Roughness Tester Features:. Profile determination Primary, waviness and roughness profile. Probe Inductive skidless probe system with ex changeable probe inserts, 2 µm probe arm, measuring force approx.
0.7 mN (standard). Filters (as per DIN/JIS) Gaussian filter, Ls filter. Standards DIN/ISO/JIS/ASME/MOTIF.
Parameters DIN/ISO: Ra, Rq, Rz, Rmax, Rp, Rv, Rpk, Rk, Rvk, Mr1, Mr2, A1, A2, Vo, Rt, R3z, RPc,. Rmr (3x), HSC, RSm, Rsk, Rdc, Rdq, Rkn, Pa, Pt, Pmr (3x), Pdc, Wa, Wq, Wt,. WSm, Wsk, JIS: Ra, Rz, RzJIS94, Sm, S, ASME: RpA, Rpm MOTIF: R, AR, Rx,. W, AW, Wx, Wte, CR, CF, CL,NR, NCRX, NW, CPM. Cutoff lc (as per ISO/JIS): 0.25 mm, 0.8 mm, 2.5 mm, automatic, MarSurf M 400 Includes:.
Drive unit MarSurf SD 26. incl. Probe system BFW 250. Standard probe arm (6852403). 1 thermo paper roll. Wide-range AC adapter mit 3 adapters.
File Explorer Software
Mahr Marsurf Ps 10
2 x USB cables (to connect to PC and for use with cable). Operating instructions All items are delivered in a practical carrying case. MarSurf M400 Bluetooth Surface Roughness Tester. Drive Unit SD 26. Traversing length 26 mm. Measuring speed 0.2 mm/s; 1 mm/s. Positioning speed in X 5 mm/s.
Height adjustment in Z 7.5 mm, motorized. Positioning speed in Z 2 mm/s. Zero setting of probe Automatically to zero value or system to specified value in the probe measuring range.
Inclination adjustment ±1.5° (alignment function with user guidance in the evaluation unit). Weight M 400: approx. 1.0 kg. SD 26: approx. 0.9 kg. Interfaces USB Slave, MarConnect (RS232). Traversing lengths Lt 1.75 mm, 5.6 mm, 17.5 mm, (as per ISO/JIS) automatic, free entry.
Traversing lengths 1 mm, 2 mm, 4 mm, 8 mm, 12 mm, 16 mm. Evaluation lengths lm (as per ISO/JIS) 1.25 mm, 4.0 mm, 12.5 mm. Number n of sampling lengths (as per ISO/JIS): selectable: 1 to 5. Short cutoff (as per ISO/JIS) selectable. Measuring speed 0.2 mm/s; 1 mm/s. Profile resolution Measuring range: ±250 µm = 8 nm, ±25 µm = 0.8 nm.
